  • M32SD
  • M42SD
  • M50SD
  • M55SD
  •

    Model
      M32SD


    Backlight Type LED
    Screen Size 32''
    Display Size(mm) 697.7(H)×392.3(V)
    Resolution 1366x768
    Brightness 320 cd/㎡
    Contrast Ratio 4000:1
    Viewing Angle 178°
    Aspect Ratio 16:9
    Colors 16.7M
    Life Time 50000 Hours
    Materials Front  Frame Black Plastic
    Housing Black Metal
    Speakers 2W x2 ,4Ω
    Input Ports Video VGA x1, HDMI x1
    Audio  Audio x 1
    Other AC IN, USB
    Source Selection VGA, HDMI, USB
    Language English, Chinese (Simplified)
    Power Consumption 43W
    Power Supply AC 110-240V (50Hz-60Hz)
    Product Size(mm) 752(H)×446(V)×57(D)
    Working Temperature 0℃ ~ 40℃
    Storage Temperature -10℃ ~ 60℃ (5℃ ~ 35℃ is recommended)
    Timer On/Off Yes
    Built in Media Player Yes (Support USB disk directly )
    Brightness Adjustment Yes (Automatically adjust the brightness value according to
    surrounding environment)
    Network Control RS232
    Supported Media Format Video: MJPEG, MPEG1, MPEG2, MPEG4, H.264, RV8, RV9, RV10, DIVX, Xvid
    Picture: JPG,BMP,PNG,JPEG
    Accessories Remote Controller, CD, QSG
  •

    Model
      M42SD


    Backlight Type LED
    Screen Size 42''
    Display Size(mm) 930.24(H)x523.26(V)
    Resolution 1920x1080
    Brightness 350 cd/㎡
    Contrast Ratio 3000:1
    Viewing Angle 178°
    Aspect Ratio 16:9
    Colors 16.7M
    Life Time 50000 Hours
    Materials Front  Frame Black Plastic
    Housing Black Metal
    Speakers 2W x2 ,4Ω
    Input Ports Video VGA x1, HDMI x1
    Audio  Audio x 1
    Other AC IN, USB
    Source Selection VGA, HDMI, USB
    Language English, Chinese (Simplified)
    Power Consumption 62W
    Power Supply AC 110-240V (50Hz-60Hz)
    Product Size(mm) 986(H)×579(V)×50(D)
    Working Temperature 0℃ ~ 40℃
    Storage Temperature -10℃ ~ 60℃ (5℃ ~ 35℃ is recommended)
    Timer On/Off Yes
    Built in Media Player Yes (Support USB disk directly )
    Brightness Adjustment Yes (Automatically adjust the brightness value according
    to surrounding environment)
    Network Control RS232
    Supported Media Format Video: MJPEG, MPEG1, MPEG2, MPEG4, H.264, RV8, RV9, RV10, DIVX, Xvid
    Picture: JPG,BMP,PNG,JPEG
    Accessories Remote Controller, CD, QSG
  •

    Model
      M50SD


    Backlight Type LED
    Screen Size 50''
    Display Size(mm) 1097.5(H)×618(V)
    Resolution 1920x1080
    Brightness 300 cd/㎡
    Contrast Ratio 1400:1
    Viewing Angle 178°
    Aspect Ratio 16:9
    Colors 16.7M
    Life Time 50000 Hours
    Materials Front  Frame Black Plastic
    Housing Black Metal
    Speakers 2W x2 ,4Ω
    Input Ports Video VGA x1, HDMI x1
    Audio  Audio x 1
    Other AC IN, USB
    Source Selection VGA, HDMI, USB
    Language English, Chinese (Simplified)
    Power Consumption 95W
    Power Supply AC 110-240V (50Hz-60Hz)
    Product Size(mm) 1139.5(H)×660(V)×45.6(D)
    Working Temperature 0℃ ~ 40℃
    Storage Temperature -10℃ ~ 60℃ (5℃ ~ 35℃ is recommended)
    Timer On/Off Yes
    Built in Media Player Yes (Support USB disk directly )
    Brightness Adjustment Yes (Automatically adjust the brightness value
    according to surrounding environment)
    Network Control RS232
    Supported Media Format Video: MJPEG, MPEG1, MPEG2, MPEG4, H.264, RV8, RV9, RV10, DIVX, Xvid
    Picture: JPG,BMP,PNG,JPEG
    Accessories Remote Controller, CD, QSG
  •

    Model
      M55SD


    Backlight Type LED
    Screen Size 55''
    Display Size(mm) 1209.6(H)×680.4(V)
    Resolution 1920x1080
    Brightness 400 cd/㎡
    Contrast Ratio 5000:1
    Viewing Angle 178°
    Aspect Ratio 16:9
    Colors 16.7M
    Life Time 50000 Hours
    Materials Front  Frame Black Plastic
    Housing Black Metal
    Speakers 2W x2 ,4Ω
    Input Ports Video VGA x1, HDMI x1
    Audio  Audio x 1
    Other AC IN, USB
    Source Selection VGA, HDMI, USB
    Language English, Chinese (Simplified)
    Power Consumption 117W
    Power Supply AC 110-240V (50Hz-60Hz)
    Product Size(mm) 1255(H)×726(V)×50(D)
    Working Temperature 0℃ ~ 40℃
    Storage Temperature -10℃ ~ 60℃ (5℃ ~ 35℃ is recommended)
    Timer On/Off Yes
    Built in Media Player Yes (Support USB disk directly )
    Brightness Adjustment Yes (Automatically adjust the brightness value according
    to surrounding environment)
    Network Control RS232
    Supported Media Format Video: MJPEG, MPEG1, MPEG2, MPEG4, H.264, RV8, RV9, RV10, DIVX, Xvid
    Picture: JPG,BMP,PNG,JPEG
    Accessories Remote Controller, CD, QSG

MxxSD series LCD Commercial Monitor, LED backlight, is ideal for education, corporate and other public applications. Compared to previous generation displays, the LED backlighting allows for reduced power consumption, a thinner depth and lighter weight.



Boasting an impressive full HD resolution with VGA, and HDMI inputs, integrated USB media player and a variety of display settings, the LCD large screen display delivers stunning visual impact with high static contrast ratio and low power consumption.



It is designed for implementation in public environments, corporate lobbies, and boardrooms, while addressing digital signage needs in retail stores, restaurants, shopping mall and so on.



Display Solution 1:

MSD commercial display + USB stick

Applicable for simple plug and plug requirement



Display Solution 2:

MSD commercial display + Media player or computer
Display Solution

Applicable for professional public display requirement



Product Pictures
Product Pictures
Product Pictures
Product Pictures
Product Pictures
Product Pictures
Product Pictures

Product information Date Language File
User Manual Universal User Manual 2015/04/09 English
QSG MxxS4&PD&MxxST&MxxSD-V1.0 2015/04/09 English
