  • GT552
  • GT655
  • GT705
  • GT842
  •

    Model
    GT552
    Backlight Type LED
    Display Screen Size 55''
    Display Size (mm) 1209.6(H) x 680.4(V)
    Resolution 1920x1080
    Brightness 400 cd/m2
    Contrast Ratio 4000:1 typ
    Aspect Ratio 16:9
    Viewing Angle 1780
    Colors 16.7M (RGB 8bits)
    Response Time 5 ms (Typ.) (G to G)
    Life Time 50000 Hours Portrait & Landscape
    Touch Frame Type 6 Points IR Touch
    Touch Size (Active Area) (mm) 1209.77±1(W) x 680.4±1(D)
    Input Method Finger, gloved hand, or any other pointer
    Touch Resolution 32768(W) x 32768(D)
    Minimum Touch Object ≧5mm
    Touch Accuracy ≦2mm
    Response Time 4-7ms
    Touch Durability Unlimited
    Operation System Win 8 / Win7 / Win XP / Vista / Linux / Android
    Interface USB 2.0 (A Type, male)
    Product Size (mm) 1274.4(H) x 758.9(V) x 85.7(D)
    Package Size (mm) 1450(H)x951(V)x256(D)
    Tempered Glass 4mm
    Light Transmission >95%
    Speaker 2 x15W
    Interface Side Input AV, RS232, VGA, YPbPr, Audio, HDMI, Multi Media USB, Touch USB
    Front Input HDMI, Touch USB, PC USB
    Output Audio, AV, VGA
    Sound Pickup Area /
    Direction
    Sensitivity
    Camera Resolution
    Video Quality
    Image/Video
    Input Power Voltage AC 110-240 V (50Hz-60Hz)
    Power Consumption Normal ≤150W
    Standby ≤1W
    Working Temperature 0℃ - 45℃
    Storage Temperature 5℃ ~ 40℃ (5℃ ~ 35℃ is recommended)
    Working Humidity 10%-80%RH, non-condensing
    Storage Humidity 35%-75%RH, non-condensing
    Accessories Remote Controller x 1, HDMI Cable 1.5M x 1, Touch Pen x 2,
    USB Extension Cable 1.5M x 1, Power Cord x 1, AAA Battery x 2
    Optional Mini built in computer, Installation Bracket
  •

    Model
    GT655
    Backlight Type LED
    Display Screen Size 65''
    Display Size (mm) 1428.48(H) x 803.52(V)
    Resolution 1920x1080
    Brightness 450 cd/m2
    Contrast Ratio 5000:1 typ
    Aspect Ratio 16:9
    Viewing Angle 1780
    Colors 1.07G (RGB 10bits)
    Response Time 5 ms (Typ.) (G to G)
    Life Time 30000 Hours Portrait & Landscape
    Touch Frame Type 6 Points IR Touch
    Touch Size (Active Area) (mm) 1430±1(W)×805±1(D)
    Input Method Finger, gloved hand, or any other pointer
    Touch Resolution 32768(W) x 32768(D)
    Minimum Touch Object ≧5mm
    Touch Accuracy ≦2mm
    Response Time 4-7ms
    Touch Durability Unlimited
    Operation System Win 8 / Win7 / Win XP / Vista / Linux / Android
    Interface USB 2.0 (A Type, male)
    Product Size (mm) 1503.6(H)x901.6(V)x85.12(D)
    Package Size (mm) 1740(H)x1185(V)x320(D)
    Tempered Glass 4mm
    Light Transmission >95%
    Speaker 2 x15W
    Interface Side Input AV, RS232, VGA, YPbPr, Audio, HDMI, Multi Media USB, Touch USB
    Front Input HDMI, Touch USB, PC USB
    Output Audio, AV, VGA
    Sound Pickup Area /
    Direction
    Sensitivity
    Camera Resolution
    Video Quality
    Image/Video
    Input Power Voltage AC 110-240 V (50Hz-60Hz)
    Power Consumption Normal ≤230W
    Standby ≤1W
    Working Temperature 0℃ - 45℃
    Storage Temperature 5℃ ~ 40℃ (5℃ ~ 35℃ is recommended)
    Working Humidity 10%-80%RH, non-condensing
    Storage Humidity 35%-75%RH, non-condensing
    Accessories Remote Controller x 1, HDMI Cable 1.5M x 1, Touch Pen x 2,
    USB Extension Cable 1.5M x 1, Power Cord x 1, AAA Battery x 2
    Optional Mini built in computer, Installation Bracket
  •

    Model
    GT705
    Backlight Type LED
    Display Screen Size 70''
    Display Size (mm) 1549.44(H) x 871.56(V)
    Resolution 1920x1080
    Brightness 400 cd/m2
    Contrast Ratio 4000:1 typ
    Aspect Ratio 16:9
    Viewing Angle 1780
    Colors 16.7M (RGB 8bits)
    Response Time 8 ms (Typ.) (G to G)
    Life Time 30000 Hours Portrait & Landscape
    Touch Frame Type 6 Points IR Touch
    Touch Size (Active Area) (mm) 1540±1(W)×869±1(D)
    Input Method Finger, gloved hand, or any other pointer
    Touch Resolution 32768(W) x 32768(D)
    Minimum Touch Object ≧5mm
    Touch Accuracy ≦2mm
    Response Time 4-7ms
    Touch Durability Unlimited
    Operation System Win 8 / Win7 / Win XP / Vista / Linux / Android
    Interface USB 2.0 (A Type, male)
    Product Size (mm) 1617.8(H)x961.9(V)x87.5(D)
    Package Size (mm) 1839(H)x1240(V)x320(D)
    Tempered Glass 4mm
    Light Transmission >95%
    Speaker 2 x15W
    Interface Side Input AV, RS232, VGA, YPbPr, Audio, HDMI, Multi Media USB, Touch USB
    Front Input HDMI, Touch USB, PC USB
    Output Audio, AV, VGA
    Sound Pickup Area /
    Direction
    Sensitivity
    Camera Resolution
    Video Quality
    Image/Video
    Input Power Voltage AC 110-240 V (50Hz-60Hz)
    Power Consumption Normal ≤350W
    Standby ≤1W
    Working Temperature 0℃ - 45℃
    Storage Temperature 5℃ ~ 40℃ (5℃ ~ 35℃ is recommended)
    Working Humidity 10%-80%RH, non-condensing
    Storage Humidity 35%-75%RH, non-condensing
    Accessories Remote Controller x 1, HDMI Cable 1.5M x 1, Touch Pen x 2,
    USB Extension Cable 1.5M x 1, Power Cord x 1, AAA Battery x 2
    Optional Mini built in computer, Installation Bracket
  •

    Model
    GT842
    Backlight Type LED
    Display Screen Size 84''
    Display Size (mm) 1860 (H) x 1046(V)
    Resolution 1920x1080
    Brightness 350 cd/m2
    Contrast Ratio 4000:1 typ
    Aspect Ratio 16:9
    Viewing Angle 1780
    Colors 16.7M (RGB 8bits)
    Response Time 5 ms (Typ.) (G to G)
    Life Time 50000 Hours Portrait & Landscape
    Touch Frame Type 6 Points IR Touch
    Touch Size (Active Area) (mm) 1860±1(W)×1046±1(D)
    Input Method Finger, gloved hand, or any other pointer
    Touch Resolution 32768(W) x 32768(D)
    Minimum Touch Object ≧5mm
    Touch Accuracy ≦2mm
    Response Time 4-7ms
    Touch Durability Unlimited
    Operation System Win 8 / Win7 / Win XP / Vista / Linux / Android
    Interface USB 2.0 (A Type, male)
    Product Size (mm) 1948.4(H) x 1162.4(V) x 100.2(D)
    Package Size (mm) 2300(H)x1570(V)x505(D)
    Tempered Glass 4mm
    Light Transmission >95%
    Speaker 2 x15W
    Interface Side Input AV, RS232, VGA, YPbPr, Audio, HDMI, Multi Media USB, Touch USB
    Front Input Touch USB, PC USB, VGA, HDMI
    Output Audio, AV, VGA
    Sound Pickup Area /
    Direction
    Sensitivity
    Camera Resolution
    Video Quality
    Image/Video
    Input Power Voltage AC 110-240 V (50Hz-60Hz)
    Power Consumption Normal ≤420W
    Standby ≤1W
    Working Temperature 0℃ - 45℃
    Storage Temperature 5℃ ~ 40℃ (5℃ ~ 35℃ is recommended)
    Working Humidity 10%-80%RH, non-condensing
    Storage Humidity 35%-75%RH, non-condensing
    Accessories Remote Controller x 1, HDMI Cable 1.5M x 1, Touch Pen x 2,
    USB Extension Cable 1.5M x 1, Power Cord x 1, AAA Battery x 2
    Optional Mini built in computer, Installation Bracket

Solution

1. LCD Interactive Whiteboard in meeting room

Goodview GT series LCD interactive whiteboard IWB is widely used in different meeting room, which replace traditional projector, its abundant features make the job to be easier than ever before.
l Interactive between people and LCD display, free from mouse, make the communication be easier. The application has control, note and write modes for option.
IWB can completely replace mouse to control computer under “control” mode.
IWB supports to make any notes on the interface if necessary under “note” mode.
IWB supports to write down any content and display out on screen under “write” mode
l Paperless, environmental protection
l Quick response, high accuracy



2. LCD Interactive Whiteboard in education

As an innovation product in education, Goodview IWB brings more interaction between teachers and students, and covers the shortage of traditional teaching method.
By using Goodview LCD interactive whiteboard, teacher can explain the curriculum more vivid, and students can increase the learning interest. Any complicated content can be shown clearly by different IWB software
Its network function makes the remote video teaching to be reality easily


Goodview IWB is using flexible connection design concept, both built in OPS or external computer and laptop can work with the unit.



Product Pictures

Product Pictures







          Product Pictures

Product Pictures



Product Pictures

Product information Date Language File
QSG Interactive WhiteBoard-QSG 2015/04/09 English
User Manual LCD Digital Signage Display User Manual 2015/04/09 English
